Size

(8000-12500)*2500*1600 (mm)

Payload

50000KG

Main beam

Heavy duty I beam.

Cylinders

HYVA

Axles

3 * 13ton capacity  (Brand optional)

Suspension

Mechanical suspension (Air suspension optional)

Leaf spring

10pcs

Tire

12R22.5  12pcs  (Other size optional)

Rim

9.00-22.5  12pcs   (Other size optional)

Kin pin

2’’/3.5’’ bolt type

Landing gear

28 Ton two speed

Braking system

Double air chamber ,brake valve,40L air tanks ;ABS optional

Electrical

LED light , 7 ways ,24V

Painting

Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
