Size

(12500-13000)*2500*1500 (mm)

Side board height

1800-2500mm optional

Payload

50000KG

Main beam

Heavy duty I beam.

Cross beam

160mm

Plate

checked plate or flat plate

Door

Side door or rear door optional

Axles

3 * 13ton capacity  (Brand optional)

Suspension

Mechanical suspension (Air suspension optional)

Leaf spring

10pcs

Tire

12R22.5  12pcs  (Other size optional)

Rim

9.00-22.5  12pcs   (Other size optional)

Kin pin

2’’/3.5’’ bolt type

Landing gear

28 Ton two speed

Twist locks

optional

Braking system

Double air chamber ,brake valve,40L air tanks ;ABS optional

Electrical

LED light , 7 ways ,24V

Painting

Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
