Size

14250*2500*1500 (mm)

Payload

30000KG+30000KG

Main beam

Heavy duty I beam.

Axles

13ton capacity  (2+2 or 3+3  optional)

Suspension

Mechanical suspension (Air suspension optional)

Leaf spring

10pcs

Tire

12R22.5  24pcs (16pcs)  (Other size optional)

Rim

9.00-22.5  24pcs (16pcs)  (Other size optional)

Kin pin

2’’/3.5’’ bolt type

Landing gear

28 Ton two speed *2

Twist locks

8pcs

Braking system

Double air chamber ,brake valve,40L air tanks ;ABS optional

Electrical

LED light , 7 ways ,24V

Painting

Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
